Light Bar WHT 4000K 24V 120° 5 years warranty
Description:
- Suitable for KBB, free combination length
- Easy to create your desired lengths and shapes thanks to our smart accessories.
- Slim in size 12.5x13mm(WxH) / 0.49"x0.51"(WxH).
Quick Detail:
· LEDLINE LIGO, DC24V.
· 100/200/500MM
· Quick DIY connection & soldering free & without light interruption in desired shapes.
· SDCM 3, One Bin Only
· Simply stick with magnetic or click with bracket.
· Max 8M single feed without brightness attenuation.
· IP20
· CE, RoHS, Reach, UL compliant
· Life Span >50000H
· 5 Year Warranty
Specifications:
| Tech Date |
|
| Model |
LEDLINE LIGO 4000K |
| LED Type |
Lumileds 2835 |
| Beam Angle |
120° |
| LED PIN Temperature |
Max.65℃ |
| Storage Temperature |
-25℃ ～ +60℃ |
| Life span |
>50000hrs |
| Certification |
CE, RoHS, Reach, UL |
| IP Grade |
IP20 |
| Warranty |
5 Years |
| Max. Production Length |
100mm, 200mm, 500mm |
| CRI |
Ra90 |
| LED Color |
White |
| Voltage |
DC24V(23.5Vmin, 24.5Vmax) |
| Color Temperature |
4000K |
| Chromaticity Coordinates (x and y) |
x=0.463 / y=0.42 |
| Power(W/M) |
1.2W/M,2.5W/M, 6W/M, |
| LM/M |
480lm @6W/M |
| Efficiency(LM/W) |
80lm/w |
Notices:
-Max 8M@100/200/500mm single feed without brightness attenuation.
-Connector should be firmly inserted at both ends of the LIGO, the maximum connection power of the same group is 100W.
Applications:
LEDLINE LIGO suitable for retail shops, KBB, gallery, show-booth and exhibition room no limits to your imagination in shape. Perfect good performance in jewelry cabinet, commodity display cabinet and interior furniture. Desired light effect in bar counter, restaurant, hotel and task lighting applications.
FAQ:
Commercial CE RoHS Reach UL Certificate Indoor IP20
Q1. Can I have a sample order for led light?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q2. What about the lead time?
A: 2-4 weeks after payment.
Q3. Do you have any MOQ limit for led light order?
A: Low MOQ, 1pc for sample checking is available.
Q4. How do you ship the goods and how long does it take to arrive?
A: Ship by DHL, UPS, FedEx or TNT. It takes 3-5 days to arrive. Airline and sea shipping also optional.
Q5. How to proceed an order for led light?
A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order.
Fourthly We arrange the production.
Q6. Is it OK to print my logo on led light product?
A: Yes. Please inform us formally before our production.
Q7: Do you offer guarantee for the products?
A: Yes, we offer 3-5 years warranty to our products.
Q8: How to deal with the faulty?
A: All LED strip are warranted to be free from defects in product itself for 3 years from the date of purchase.
This warranty does not cover failures due to abuse, misuse, improper handling, act of nature, negligence, normal wear, accidental damage, modifications or repairs made by the purchaser or incorrect voltage conditions.
